New Mexico Summer Monsoon Season Precipitation Mapping
Updated: 04-01-2025
The maps below are focused on capturing unique elements of the summer monsoon season across New Mexico including total precipitation, intensity, and frequency of precipitation events. Maps are updated once a day from June 15 - September 30th using gridded precipitation data (nominally 4km by 4km) provided by the NOAA National Water Prediction Service. The gridded data provide a spatial estimate of true precipitation amounts across the region and should be interpreted with caution at very fine scales. Note that radar coverage is limited across the Four Corners and precipitation amounts will be underestimated across this region. More information on how the gridded data are produced can be found here.
Companion SW Monsoon climate monitoring products:
- Southwest U.S. Monsoon Season Technical Summaries
- Southwest Summer Monsoon Season Precipitation Mapping (PRISM data)
- Arizona Summer Monsoon Season Precipitation Mapping (NOAA-AHPS data)
Email Mike Crimmins with questions and/or suggestions on how to improve these plots or ideas for additional variables
Total precipitation: Daily precipitation data summed
from 6/15 to present. (Alternate
color scale, Colorblind-friendly)
Percent of days with rain: A count of days observing greater than or equal to 0.01” of rain divided by the number of days between 6/15 and the current date. A value of 50% indicates that rain was observed on half of the days between 6/15 and the current date.
Max 1-day precipitation: This maps shows the single
maximum 1-day precipitation amount observed in each data grid cell
between 6/15 and the current date. (Colorblind-friendly)
Most Recent 24-hr Precipitation (ending 5am MST on date listed)
Percent of average precipitation: Percent of average is calculated by dividing the total accumulated precipitation by the long-term (1991-2020) mean and is an indication of how much totals have deviated from average precipitation for the June 15th to present period. 100% is equal to average for the time period shown on the map. (Seasonal Average Total Precipitation)
Daily intensity index: This index is the simple ratio between the total precipitation over the time period and the number of days observing rain with units in ‘inches/day’. A high value indicates that most of the total precipitation came in a small number of large or intense events.
Days since 0.05” rain event: This map indicates the number of days since at least a precipitation amount of 0.05” was observed in each data grid cell. Higher values indicate a longer time period or break since at least light rainfall was observed.
Daily change in precipitation anomaly coverage: This figure depicts the daily change in the coverage of different categories of precipitation anomalies or differences from average. It is calculated by counting the number of grid cells in each anomaly category (e.g. below or above average) each day and then dividing it by the total number of grid cells for New Mexico. For example, if the brown or below average category is greatest for any given day, then that indicates most of the state was observing below average precipitation.
